The photosensitive element: the original chips
The lens size: Standard 3.6MM, optional 2.8MM
Signal format: PAL
Color: color
Waterproof grade: 1P66
Power supply: DC12V+-1
Signal to noise ratio: >52DB
Maximum power: the maximum power dissipation of 12W
Minimum illumination: LUUX (IR LED on)
Video output: 1.0vp-P, 75
Gain control: automatic
Backlight compensation: automatic
Exposure mode: electronic exposure
Synchronization: synchronization
Working temperature: -15 degrees to 80 degrees
Lens selection reference:
The irradiation angle of shot size recommended irradiation distance
4mm 69.9 degree 0-6 meters
6mm 50 degree 6-10 meters
8mm 38.5 degree 10-20 meters
12mm 26.2 degree 20-35 meters
16mm 26.2 degree 30-50 meters
