You are here:Home >> Products >> Car LCD Monitor >> 5-inch Series
Name:5 inch car monitor, 2 video,Foldable appearance
Model:JL-YJC-5007
Category:5-inch Series
Product Features:
5 inch monitor,TFT-LCD,2 video,foldable appearance,HD800*480,DC9-35V


Model: JL-YJC-5007
Folding appearance of 5-inch TFT-LCD
1. Interface: AV 2-channel video input, power standard interface. PAL / NTSC is adaptive.
2. LCD screen: full screen 16:9, 4:3 can be set
3. Visual range: 101.568 (W) x76.176 (H) mm
4. Visible wide angle: L / R / U / D: 70 ° / 70 ° / 50 ° / 70 °
5. Power supply voltage: DC 9V ~ 35V wide voltage
6. Brightness: 250 ~ 300 CD / m2
7. Contrast: 350:1
8. Resolution: 800X (RGB) x480dots
9. Current consumption: 200mA
10. Power consumption: 3W
11. Operating temperature: - 20 ℃ - + 50 ℃
