PC player software can select open shut down all the way audio.
Audio output audio output all the way
The recording mode Voice recording and video real-time synchronization
Audio compression ADPCM/g. 726
Image compression, h. 264 variable stream (VBR)
CIF quality image format
Video bit rate can choose 1 m 512 k, 256 k to 128 k
Standard ADPCM audio stream
The audio bitrate 8 KB/s
Data storage SD card to store the video (optional loop video) optional support dual sim function
Automobile black box standard function superposition of real-time display speed,
brake signal, license plate number, and date/time
The input and output an alarm signal input; Alarm signal source is optional
Serial interface (reserve) supports a RS232 serial interface docking, docking with the GPS, the meter and other equipment
Player software Computer playback analysis Can sync automatically playback four-way video files and automatically play the next set of files;
Each can be individually amplified all the way
Achieve preview drag, four times the speed quick playback function
Working voltage DC 12 to 36 v
Working current < 150 ma (24 v) (excluding camera)
Working temperature 20 ℃ ~ 85 ℃
Installation dimensions L120mm * H44mm W168mm
1.0 kg weight (including packaging)
Software upgrade Native support SD card upgrade
Power output DC 12 v / 5 a
