The main technical parameters
Model: JL-YJC-9001
AV two-way video input, reversing switch,
the red/black line access or standard receptacle.
LCD screen aspect ratio: 16:9 ratio can be set to (4:3)
Visual wide Angle: 120 * 90 (H) (V)
The power supply voltage: DC 12 v
Resolution: 800 x 480 (RGB)
Screen size: diagonal 9 inches
Operating temperature: - 20 ℃ to + 65 ℃
Storage temperature: 25 ℃ to + 85 ℃
Monitor overall dimensions: dimensions: 230 * 155 * 28 (MAX.) mm
Head box opening size: 235 * 160 * 28 mm
Head box shape size: 257 * 177 * 33 mm
Aseismic levels: level 5
PAL/NTSC system adaptive,
Head and two stents
